| Media Source |
HDD |
3.5-inch SATA, NTFS (auto file format w/o PC) |
HDD Capa
|
Up to 4TB |
HDD Bay |
Dual HDD (2*HDD) |
| Video Playback |
CODEC |
H.264, WMV9, MKV, MPEG2 HD (ts,tp), HD AVI, RMV,
MPEG1/2(mpg,vob,ifo,iso), AVI, Bluray (M2TS) |
| Resolution |
Max. 1920x1080p
|
| Suctitle |
smi, ssa, srt utf-8, idx-sub, sub
|
| Audio Playback |
CODEC |
Dolby Digital, DD True-HD, MP3, AC3, WMA, OGG, WAV,
DTS, DTS HD |
| Photo playback |
Photo |
JPG Image files, BMP (32bit) |
| |
AV-in Encoding |
Recording Mode
|
HQ, SP, LP, EP, SLP |
Video Format
|
MPEG2 (PAL/NTSC) |
Audio Format |
MPEG2 |
AV Source
|
Digital STB, VCR, Canal Decoder, TV |
DVBT Recording
|
Video format
|
MPEG2 TS / MPEG4 HD TS |
TV Tuner |
DVBT SD/HD |
Mpeg2 / Mpeg4 (SD/HD) |
Network |
Network? Server |
Samba, FTP |
Network? Client |
Samba / NFS, UPNP |
File Management |
Interactive |
Device <-> Networked PC |
| |
Extension |
USB |
USB2.0 (Host*2 & Slave*1) |
Wire LAN |
10/100Mbps |
Wireless LAN |
801.11B/G or 801.11N - Optional |
Card Reader |
SD, MS, MMC (Writing option) |
Power |
Input |
AC 100V-240V, 50/60Hz |
Output |
DC 12V, 4.0A |
Power
Consumption |
Standby |
1W (0W when switched off) |
During Recording |
36W |
OS Compatibility |
Windows98/SE/ME/2000/XP/Vista |
| |
Operating Temperature/Humidity |
Cels. 0~50 / 10%~70% |
Dimension |
218*171*63mm (WDH) |
Weight |
Net 960G w/o HDD |
Accessories |
AV Cable (1*1.2m), USB Cable (1*A to B 1.2m), 50 key
Remote,Batteries (AAA*2), AC Adapter (12V), Power Cable
(1*1.2m),User Manual (One available / Multi-Language Optional) |
|
|
| |
| |
|
|
|
|
